CONSTRUCTION
Our Thermoplastic LED Edge Lit Exit Sign has been developed with style, ease of installation and dependability in mind. Utilizing ultra-bright, energy-efficient indirect LED technology, this LED Edge Lit Exit Sign provides a surface mounted edge-lit EXIT sign with excellent light distribution. The Thermoplastic LED Edge Lit Exit Sign with EZ-snap mounting canopy included may be top, end or back mounted. The Thermoplastic LED Edge Lit Exit Sign is available in Battery-Backup only models. The LED Edge Lit Exit Sign features universal field adjustable chevrons.

INTERNAL SPECIFICATIONS
BATTERY-BACKUP: comes standard configured with high-output LED technology, Dual 120/277VAC voltage. Long-life rechargeable Nickel-cadmium batteries provide a minimum 90 minutes of emergency duration. Solid state charger & transfer. Push to Test Switch for mandated code compliance testing.

EXTERNAL SPECIFICATIONS
The housing is constructed by injected-molded, engineering-grade 5VA, flame retardant, high-impact resistant thermoplastic housing in white or black finish. Self-adhesive chevron appliques and guide template provided for directional indication.

INSTALLATION
The LED Edge Lit Exit Sign is suitable for top, end or back mount. Suitable Damp Locations.

EDGE-LIT DESIGN
The LED Edge Lit Exit Signs feature a clean and contemporary look. The design brings style and flexibility to your next prestigious exit sign application. The indirect LED illumination evenly lights the acrylic face with crisp, even light. The ultra thin face plate virtually disappears once installed, yet the EXIT lettering boldly distinguishes the path of egress.

ELECTRICAL SPECIFICATIONS
The LED Edge Lit Exit Sign is configured with high-output Red or Green LED's. Standard with 120/277VAC input.

DIMENSIONS
13 7/8" Length 10 7/8" Height 1 3/4" Width

LISTINGS
UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local & state codes
